D Pod 3.0 Plus

Collaborative Acoustic Pod for Meetings and Discussions

The D POD 3.0 Plus accommodates 2 to 4 people in a comfortable and private acoustic meeting space. Designed for discussions, collaboration, and virtual meetings, it helps teams stay focused and productive without workplace distractions.

27.6 dB

Speech Level Reduction

96 %

Recyclability rate per UL ECVP 2789

0.33 A

Power Consumption

498 KG

Pod Weight

Technical Specification

Designed around the way you work.

A

D

B

F

F

C

E

E

Accoustic Properties

27.6 dB according to ISO 23351-1 Speech Level Reduction, DS, A

Material and Dimension

Material: 1.2MM Electro Galvanize Steel

Dimension (External & Internal):
2200MM(W) x 1250MM(D) X 2280MM (H)
2030mm(W) x 1160mm(D) x 2030mm (H)

External and Internal Finishing

External Finishing: Epoxy Powder Coating

Internal Finishing:
Polyester Fiber Acoustic Board

Floor Finishing:
Fiber Nylon Carpet (Black)

Glass Material

Glass Door: Aluminum Frame with 9.52mm Tempered Laminated Glass

Rear Glass: 8mm Tempered Glass

Others Specifications (Door, Table, Universal Socket, Ventilation Fam, Motion Sensor, Lighting LED)

Door Closer: Yes

Table: Melamine Laminated Wood with Chamfered Edge (700mm x 550mm x 25mm)

AH Meyer Netbox Flush 1 Power Socket & USB A+C: Rated for 110V to 250V with a maximum of 20A. USB A + C, Max 65W.

CAT 6 LAN Outlet: 1 No x CAT 6

Ventilation Fan (4 Fans): 118 CFM per Fan

Motion Sensor: 12V DC, Sensor Duration Adjustable

Lighting LED 4000K: 2 X (11W)

Occupancy Indicator Light: Yes

Air Purifying System: 2 Set HEPA Filter

Heavy Duty Castor: 4Pcs

Adjustable Foot Cap: 6Pcs

Power Consumption

Power Consumption: 0.33A

Weight

Net Weight (KG): 498

Packing Weight (KG): 673

Wooden Crate Size

Wooden Crate Size: 2278W x 1368D x 958H (2.99 M3)

New Interface Control Hub

Able to adjust:

Light Brightness
Fan Speed
Sensor Duration
Occupancy Light Mode
Intermittent Air Circulation Duration
